Pennsylvania Canal Maps

Map Book #6

Please select a map tile to view larger version (individual tiles are PDF files, approximately 1-2 MB in size)



Book 06, page 00

Index. (1 section)

Book 06, page 01

"A Map and Profile For a Slack Water Navigation Along the Ohio River From Pittsburgh to Beaver as Examined in 1828 by Edward F. Gay, Engineer." (2 sections)

Book 06, page 02

[From Pittsburgh to Jack's Run, 4 miles], n.d. Shows: Allegheny Town, Glass House Ripple, Bruno's Island, McKee's Island. (2 sections)

Book 06, page 03

[From 5 miles to Kill Buck Run, 8 miles], n.d. Shows: 1st. Part, Dam No. 1, Turkey Foot Rocks, 2nd. Part, Dam No. 1, Lock No. 1, Channel for the Improvements. (2 sections)

Book 06, page 04

[From Marion's Run, 9 miles to 13 miles], n.d. Shows: Middletown, Wolsey's Trap Ripple, Dam No. 2, Lock No. 2. (2 sections)

Book 06, page 05

[From Deadman's Ripple, 14 miles to Economy, 17 miles], n.d. Shows: Dam No. 3, Lock No. 3, Sweekly Bar. (2 sections)

Book 06, page 06

[From Croll's Run, 18 miles to Hog Island, 21 miles], n.d. Shows: Log Town Ripple, Crow Island. (2 sections)

Book 06, page 07

[From Waller's Ripple, 22 miles to Bridgewater, 25 miles], n.d. Shows: Dam No. 4, Lock No. 4, Phillipsburgh. Vignette: Genl. Lacock's home. (2 sections)
